PURe® FOLD Door System
A revolutionary range of aluminium folding doors
Specification
Typical Sizes: 1000mm x 2616mm
U-values as low as: 0.88 W/m2 K
Security: PAS24 & Secure by Design
Testing: BS6375-1, BS6375-2
Recyclable: Cradle-to-Cradle
Introducing
PURe® FOLD
Ideally suited for both domestic and commercial applications, our popular PURe® FOLD folding sliding door combines stunning aesthetics and slim sightlines with exceptional thermal efficiency.
Featuring our patented PUR technology, the system can achieve exceptionally low U-values and is fully compatible with our full range of aluminium windows and curtain wall systems.
Impressive thermal performance and stylish looks, offering ultra-low U-values
Performance
- Designed with an innovative, enhanced thermal barrier manufactured from expanded polyurethane (PUR), allowing ultra-low U values to be achieved.
- Further thermal enhancement is possible using 2 different backer rods, to achieve required U-values.
- Able to receive double or triple glazing from 24mm up to 48mm.
- Fully security tested to PAS24 Enhanced Security and Secured by Design.
- Tested to BS6375 Part 1 Weather; BS6375 Part 2 Operation & Strength.
Materials and Finishes
- All materials are responsibly sourced from reputable suppliers.
- Wherever possible we source locally.
- Extruded aluminium is generally Aluminium Alloy 6060.T6/T66. 6063.T6/T66. 6082.T6 to BS EN 755-9 and EN 12020-2.
- The Gasketry is generally manufactured in accordance with BS ISO 3302-1.
- The fixings are generally A2 stainless steel screws.
- Available in an almost unlimited range of colours and a variety of finishes.
Easy to Fabricate and Install
- Simple to fabricate using existing tooling.
- Constructed using mitred and crimped corners with support chevrons and cleats.
- A proprietary sealant is used on all metal joints.
Clever Design and Stylish Aesthetics
- Available in an almost unlimited range of colours and finishes both inside and out.
- Capable of accepting glazing up to 48mm thick.
- Fully compatible with all our windows and curtain wall systems.
Market Leading Customer Support
- Short lead times.
- Nationwide branch network and distribution centres serviced by a large fleet of eco delivery vehicles.
- Fabrication training and tooling provided if required.
- Full technical support, documentation and certification from our technical department.
- Regional advice and support via our technical sales managers and specification teams.
Technical Datasheet
PURe® FOLD folding Sliding Door System Technical Datasheet.
